Small businesses are facing a number of challenges due to new and emerging technology, making it pretty overwhelming to keep up.  Aruba   Instant On Access Points (APs) are easy to deploy and manage—with a quality look and feel at an attractive price point

Key Features of Aruba Instant On AP11:

  •   Smart Mesh technology .
  •   802.11ac Wave 2 2X2:2 MU-MIMO radios
  •   Separate guest and employee Wi-Fi network
  •   Easy client/device blocking
  •  Simple to use bandwidth tuning for power-users
  •  Easy-to-use web and mobile app for setup and management
  •  App bandwidth limiting per network/user session

Key Features of Aruba Instant On AP12:

  •   Smart Mesh technology
  •   802.11ac Wave 2 3X3:3 MU-MIMO radios
  •   Remote management and monitoring capability
  • Mobile app in multiple languages and cloud portal
  • Built-in DHCP/NAT support

Key Features of Aruba Instant On AP15:

  •  Smart Mesh technology
  • 802.11ac Wave 2 4X4:4 MU-MIMO radios
  • Separate guest and employee Wi-Fi network
  • Mobile app in multiple languages and cloud portal
Technical Specification
Aruba Instant On AP11 (RW) Access Point – HP Aruba Instant On AP12 (RW) Access Point – HP Aruba Instant On AP15 (RW) Access Point – HP
Product Description Aruba Instant On AP11 (RW) 2×2 11ac Wave2 Indoor Access Point. Aruba Instant On AP12 (RW) 3×3 11ac Wave2 Indoor Access PointAruba Instant On AP12 (RW) 3×3 11ac Wave2 Indoor Access Point Aruba Instant On AP15 (RW) 4×4 11ac Wave2 Indoor Access Point
Radios Dual radio for simultaneous dual-band operation, 5 GHz 802.11ac 2×2 MIMO for up to 867 Mbps wireless data rate, with Multi User MIMO support (Wi-Fi 5). Dual Radio for simultaneous dual-band operation,5 GHz 802.11ac 3×3 MIMO for up to 1,300Mbps wireless data rate, with Multi User MIMO support (Wi-Fi 5) Dual Radio for simultaneous dual-band operation,5 GHz 802.11ac 3×3 MIMO for up to 1,733Mbps wireless data rate, with Multi User MIMO support (Wi-Fi 5)
Interfaces Uplink Gigabit Ethernet port, with PoE-in support (802.3af)
DC power connector (12V) Bluetooth Low Energy (BLE) radio DC power connector (12V) DC power connector (12V)
LED status indicators (2) USB host interface (future use) USB host interface (future use)
Reset/LED control button Bluetooth Low Energy (BLE) radio Bluetooth Low Energy (BLE) radio
LED status indicators (2)
Reset/LED control button
Kensington security slot
Antennas Integrated down-tilt omni-directional antennas with maximum individual antenna gain of 3.3dBi in 2.4GHz and 5.8dBi in 5GHz Integrated downtilt omni-directional antennas with maximum individual antenna gain of 3.9dBi in 2.4GHz and 5.4dBi in 5GHz
Power Power over Ethernet (POE): 802.3af (class 3)
Max power consumption (worst-case): 10.1W (PoE), 8.8W (DC) Max power consumption (worst-case): 13.0W (PoE), 12.0W (DC) Max power consumption (worst-case): 14.4W (PoE), 12.7W (DC)
DC power (12V)
Mounting The access point ships with a (black) mount clip to attach to suspended ceiling rails, and a (white) mount clip to attach to solid surfaces (wall/ceiling)
Management options Instant On mobile application (Android & iOS), Cloud Portal: Portal.ArubaInstantOn.com
Content 1 x Aruba Instant On AP11 Indoor Access Point, 1 x Aruba Instant On AP11 Quick Start guide,1 x ceiling rail mount clip,1 x solid surface mount clip,1 x Ethernet cable 1 x Aruba Instant On AP12 Indoor Access Point,1 x Aruba Instant On AP12 Quick Start guide,1 x ceiling rail mount clip ,1 x solid surface mount clip,1 x Ethernet cable 1 x Aruba Instant On AP15 Indoor Access Point,1 x Aruba Instant On AP15 Quick Start guide,1 x ceiling rail mount clip ,1 x solid surface mount clip
Warranty & Support Aruba Instant On 1 Year warranty with 24X7 phone support for first 90 days and chat support for the entire warranty period. Community support as long as you own the products. Aruba Instant On 1 Year warranty with 24X7 phone support for first 90 days and chat support for the entire warranty period. Community support as long as you own the products. Aruba Instant On 1 Year warranty with 24X7 phone support for first 90 days and chat support for the entire warranty period. Community support as long as you own the products.
