Small businesses are facing a number of challenges due to new and emerging technology, making it pretty overwhelming to keep up. Aruba Instant On Access Points (APs) are easy to deploy and manage—with a quality look and feel at an attractive price point
Key Features of Aruba Instant On AP11:
- Smart Mesh technology.
- 802.11ac Wave 2 2X2:2 MU-MIMO radios
- Separate guest and employee Wi-Fi network
- Easy client/device blocking
- Simple to use bandwidth tuning for power-users
- Easy-to-use web and mobile app for setup and management
- App bandwidth limiting per network/user session
Key Features of Aruba Instant On AP12:
- Smart Mesh technology
- 802.11ac Wave 2 3X3:3 MU-MIMO radios
- Remote management and monitoring capability
- Mobile app in multiple languages and cloud portal
- Built-in DHCP/NAT support
Key Features of Aruba Instant On AP15:
- Smart Mesh technology
- 802.11ac Wave 2 4X4:4 MU-MIMO radios
- Separate guest and employee Wi-Fi network
- Mobile app in multiple languages and cloud portal
| Technical Specification | |||
| Aruba Instant On AP11 (RW) Access Point – HP | Aruba Instant On AP12 (RW) Access Point – HP | Aruba Instant On AP15 (RW) Access Point – HP | |
| Product Description | Aruba Instant On AP11 (RW) 2×2 11ac Wave2 Indoor Access Point. | Aruba Instant On AP12 (RW) 3×3 11ac Wave2 Indoor Access PointAruba Instant On AP12 (RW) 3×3 11ac Wave2 Indoor Access Point | Aruba Instant On AP15 (RW) 4×4 11ac Wave2 Indoor Access Point |
| Radios | Dual-radio for simultaneous dual-band operation, 5 GHz 802.11ac 2×2 MIMO for up to 867 Mbps wireless data rate, with Multi-User MIMO support (Wi-Fi 5). | Dual Radio for simultaneous dual-band operation,5 GHz 802.11ac 3×3 MIMO for up to 1,300Mbps wireless data rate, with Multi-User MIMO support (Wi-Fi 5) | Dual Radio for simultaneous dual-band operation,5 GHz 802.11ac 3×3 MIMO for up to 1,733Mbps wireless data rate, with Multi-User MIMO support (Wi-Fi 5) |
| Interfaces | Uplink Gigabit Ethernet port, with PoE-in support (802.3af) | ||
| DC power connector (12V) Bluetooth Low Energy (BLE) radio | DC power connector (12V) | DC power connector (12V) | |
| LED status indicators (2) | USB host interface (future use) | USB host interface (future use) | |
| Reset/LED control button | Bluetooth Low Energy (BLE) radio | Bluetooth Low Energy (BLE) radio | |
| LED status indicators (2) | |||
| Reset/LED control button | |||
| Kensington security slot | |||
| Antennas | Integrated down-tilt Omni-directional antennas with a maximum individual antenna gain of 3.3dBi in 2.4GHz and 5.8dBi in 5GHz | Integrated down-tilt omni-directional antennas with a maximum individual antenna gain of 3.9dBi in 2.4GHz and 5.4dBi in 5GHz | |
| Power | Power over Ethernet (POE): 802.3af (class 3) | ||
| Max power consumption (worst-case): 10.1W (PoE), 8.8W (DC) | Max power consumption (worst-case): 13.0W (PoE), 12.0W (DC) | Max power consumption (worst-case): 14.4W (PoE), 12.7W (DC) | |
| DC power (12V) | |||
| Mounting | The access point ships with a (black) mount clip to attach to suspended ceiling rails, and a (white) mount clip to attach to solid surfaces (wall/ceiling) | ||
| Management options | Instant On mobile application (Android & iOS), Cloud Portal: Portal.ArubaInstantOn.com | ||
| Content | 1 x Aruba Instant On AP11 Indoor Access Point, 1 x Aruba Instant On AP11 Quick Start guide,1 x ceiling rail mount clip,1 x solid surface mount clip,1 x Ethernet cable | 1 x Aruba Instant On AP12 Indoor Access Point,1 x Aruba Instant On AP12 Quick Start guide,1 x ceiling rail mount clip,1 x solid surface mount clip,1 x Ethernet cable | 1 x Aruba Instant On AP15 Indoor Access Point,1 x Aruba Instant On AP15 Quick Start guide,1 x ceiling rail mount clip,1 x solid surface mount clip |
| Warranty & Support | Aruba Instant On 1 Year warranty with 24X7 phone support for the first 90 days and chat support for the entire warranty period. Community support as long as you own the products. | Aruba Instant On 1 Year warranty with 24X7 phone support for the first 90 days and chat support for the entire warranty period. Community support as long as you own the products. | Aruba Instant On 1 Year warranty with 24X7 phone support for the first 90 days and chat support for the entire warranty period. Community support as long as you own the products. |
Call Amanveer at +91-11-69039090 at extn. 101 to discuss or email us at sales@eagle.in
